- GRADE: FC422
- Bead Size: 0.5-0.7 mm
- Pentane Content: >5% wt%
- K-Value: 55
- Expanded Density: 20-30 kg/m3
- Packaging: 55*25 Kg shrink-wrapped wooden pallets
- HS Code: 39031190
- PRODUCER: Tabriz Petrochemical Company
EPS 422FC
Category: EPS
Description
FC422 represents an advanced formulation within TPC’s Performance expandable polystyrene (EPS) product portfolio. This specialized grade consists of precisely engineered spherical polystyrene beads with integrated pentane expansion agent, designed specifically for applications requiring superior molding cycle efficiency and enhanced moisture resistance. Distinguished by its optimized small bead size morphology (0.5-0.7mm), FC422 delivers exceptional performance in thin-wall applications while maintaining excellent mechanical resilience. The material achieves industry-standard densities of approximately 25 kg/m³ while incorporating proprietary formulation elements that enhance both processing efficiency and end-product performance characteristics.
- Optimized Bead Morphology: Small bead size profile (0.5-0.7mm, >90% by weight) enabling superior thin-wall applications
- Enhanced Processing Efficiency: Fast-cycling formulation significantly reduces production cycle times
- Hydrophobic Properties: Specialized water-resistant formulation prevents moisture absorption
- Controlled Expansion Characteristics: Engineered to achieve uniform low-density foam without agglomeration during pre-expansion
- Defined K-Value Parameters: Specified 52-57 K-value range ensuring consistent processing behavior
- Antistatic Protection: Integrated antistatic treatment prevents electrostatic charge accumulation during material handling
- Closed-Cell Architecture: Engineered structural configuration optimized for impact energy absorption
- Volumetric Stability: Maintains dimensional integrity across operational temperature ranges
FC422’s unique molecular structure and processing characteristics make it particularly suitable for:
- Thin-Wall Contour Moldings: Specialized performance in applications with wall thicknesses below 10mm
- Rapid-Cycle Production Systems: Engineered for manufacturing contexts requiring accelerated cooling periods
- Moisture-Sensitive Environments: Enhanced water resistance properties for applications exposed to humid conditions
- Complex Geometric Formations: Superior mold-filling capabilities for intricate structural requirements
- Impact-Absorption Systems: Engineered closed-cell structure optimized for controlled energy dissipation
- High-Volume Production Requirements: Fast-cycling characteristics support efficient manufacturing throughput
- Manufacturing Efficiency: Accelerated cooling periods significantly reduce production cycle times
- Application Versatility: Enhanced molding capabilities in both thin-wall and standard applications
- Moisture Performance: Superior resistance to humidity and water exposure maintains structural integrity in challenging environments
- Exceptional Mold Filling: Superior flow characteristics enable precise replication of complex geometries
- Impact Protection: Engineered cellular structure provides controlled deformation under impact loading
- Processing Flexibility: Compatible with industry-standard molding equipment across diverse steaming parameters
- Dimensional Precision: Consistent material expansion characteristics ensure reliable end-product dimensions
- High-Volume EPS Processors: Manufacturing operations requiring accelerated production cycles
- Thin-Wall Component Fabricators: Manufacturers of precision-molded components with minimal wall thickness requirements
- Moisture-Resistant Packaging Developers: Companies producing packaging for humidity-sensitive applications
- Complex Geometry Molders: Fabricators producing intricate shapes requiring superior mold-filling characteristics
- Industrial Component Manufacturers: Producers of technical parts requiring consistent dimensional stability
- Impact Protection System Developers: Designers of energy-absorbing protective structures
- Pre-expansion Density: Optimally processes to approximately 25 kg/m³
- Intermediate Aging Period: 10-48 hours for optimal material stabilization
- Storage Temperature: Below 20°C for maintained material properties
- Processing Window: Within 1 month of material receipt for optimal performance
- Molding Compatibility: Standard industry molding equipment with flexible steaming parameters
- Cooling Cycle: Reduced cooling requirements compared to standard EPS grades
- Pre-expansion Protocol: Achievable density of approximately 25 kg/m³ in state-of-the-art discontinuous pre-expanders
- Density Optimization: Lower density values attainable through double pre-expansion methodology or equipment optimization
- Intermediate Conditioning Period: 10-48 hours recommended for optimal processing stability
- Molding Compatibility: Processable in standard industry molding systems with adaptable steam parameter configurations
- Regenerative Material Integration: Requires careful density matching between regenerative agent and expanded material to prevent segregation during production
- Primary Containment: Octabins (non-weather/water-proof)
- Container Dimensions: Height 176 cm
- Pallet Configuration: Wooden pallets measuring 115 cm × 115 cm
- Net Content Weight: 1000 kg per octabin
- Storage Requirements: Indoor storage below 20°C in dry conditions
- Handling Considerations: Material includes antistatic treatment but containers require protected storage
FC522 is supplied in a standardized containment system:
Industrial Octabin Configuration
- 1000 kg net material content
- Container dimensions: 115 cm × 115 cm × 176 cm (height)
- Mounted on standardized wooden pallets (115 cm × 115 cm)
- Non-weatherproof construction requiring indoor storage
| Property | Unit | Test Method | Specification Range | Typical Value |
| K-Value | – | SUNPOR 7.2.4 | 52-57 | 55 |
| Bead Size | mm | SUNPOR 7.2.5 | 0.5-0.7 (>90% by weight) | 0.5-0.7 (>90% by weight) |
| Pentane Content | wt% | SUNPOR 7.2.2 | Min 5.2% | >5% |
| Residual Monomer | ppm | SUNPOR 7.2.1 | Max 1000 | 500 |
| Moisture Content | wt% | SUNPOR 7.2.3 | Max 1% | – |
| Expanded Density | kg/m³ | SUNPOR 7.2.6 | – | 20-30 |
